Технические характеристики серии-К, мощность – 1,1kW [1]
|
Output speed n2 [r/min] |
Output torque Ta [N*m] |
Ratio i |
Permitted overhung load FR2 [N] |
Service factor fB |
Model |
|
|---|---|---|---|---|---|---|
|
1.1kW |
||||||
|
0.15 0.17 0.19 0.21 0.23 0.26 0.29 0.32 |
60700 52400 48300 44300 39200 34900 31200 28300 |
9363 8126 7343 6747 5991 5358 4817 4370 |
171000 185900 190000 190000 190000 190000 190000 190000 |
0.80 0.95 1.05 1.15 1.30 1.45 1.60 1.75 |
K |
187R97 D90S4 |
|
0.26 0.29 0.34 0.41 0.51 |
35000 31200 26800 22200 18000 |
5355 4788 4079 3376 2755 |
150000 150000 150000 150000 150000 |
0.90 1.05 1.20 1.45 1.80 |
K |
167R97 D90S4 |
|
0.64 0.82 0.99 1.1 |
14600 11300 9330 8560 |
2182 1704 1408 1296 |
150000 150000 150000 150000 |
2.2 2.8 3.4 3.7 |
K |
167R97 D90S4 |
|
0.40 0.46 0.54 0.60 |
22900 20100 16900 15100 |
3516 3051 2610 2322 |
109300 111100 112700 113500 |
0.80 0.90 1.05 1.20 |
K KF KA KAF |
157 R97 D90S4 157 R97 D90S4 157 R97 D90S4 157 R97 D90S4 |
|
0.84 1.0 1.1 1.3 1.5 1.6 |
11000 8970 8030 7150 6160 5550 |
1659 1365 1229 1093 942 854 |
115000 115600 115800 116000 116100 116200 |
1.65 2.0 2.2 2.5 2.9 3.2 |
K KF KA KAF |
157 R97 D90S4 157 R97 D90S4 157 R97 D90S4 157 R97 D90S4 |
|
0.73 0.80 0.91 1.0 1.2 1.4 1.6 1.8 2.0 2.3 2.5 2.9 |
13100 11900 10400 9100 7960 6950 6080 5270 4740 4090 3690 3180 |
1926 1757 1541 1342 1177 1025 899 790 704 610 549 477 |
79100 79800 80500 81100 81500 81800 82000 82200 82400 82500 82500 82600 |
1.00 1.10 1.25 1.45 1.65 1.85 2.1 2.5 2.7 3.2 3.5 4.1 |
K KF KA KAF |
127 R77 D90S4 127 R77 D90S4 127 R77 D90S4 127 R77 D90S4 |
|
1.2 1.4 1.5 1.8 2.0 2.3 2.7 3.0 3.4 3.8 4.4 |
7920 6920 6050 5380 4700 4120 3500 3080 2720 2450 2140 |
1166 1030 904 793 696 615 522 461 408 364 318 |
65000 65000 65000 65000 65000 65000 65000 65000 65000 65000 65000 |
1.00 1.15 1.30 1.50 1.70 1.95 2.3 2.6 2.9 3.3 3.7 |
K KF KA KAF |
107 R77 D90S4 107 R77 D90S4 107 R77 D90S4 107 R77 D90S4 |
|
1.9 2.2 2.4 2.8 3.2 3.7 4.1 |
5030 4420 3910 3400 2940 2590 2300 |
743 652 573 504 437 382 342 |
39900 40000 40000 40000 40000 40000 40000 |
0.85 0.95 1.10 1.25 1.45 1.65 1.85 |
K KF KA KAF |
97 R57 D90S4 97 R57 D90S4 97 R57 D90S4 97 R57 D90S4 |
|
3.0 3.3 3.8 4.2 4.8 5.6 5.9 7.0 |
3220 2890 2520 2230 1980 1700 1600 1360 |
474 426 373 330 294 250 236 201 |
26600 27000 27500 27800 28100 28300 28400 28600 |
0.85 0.95 1.05 1.20 1.35 1.60 1.70 2.0 |
K KF KA KAF |
87 R57 D90S4 87 R57 D90S4 87 R57 D90S4 87 R57 D90S4 |
|
3.9 4.4 4.8 5.5 |
2720 2370 2170 1910 |
176.05 153.21 140.28 123.93 |
40000 40000 40000 40000 |
1.60 1.80 2.0 2.2 |
K KF KA KAF |
97 D100L8 97 D100L8 97 D100L8 97 D100L8 |
|
5.2 6.0 6.6 7.4 |
2010 1750 1600 1420 |
176.05 153.21 140.28 123.93 |
40000 40000 40000 40000 |
2.1 2.5 2.7 3.0 |
K KF KA KAF |
97 D90L6 97 D90L6 97 D90L6 97 D90L6 |
|
7.9 9.1 10 |
1320 1150 1050 |
176.05 153.21 140.28 |
40000 40000 40000 |
3.3 3.7 4.1 |
K KF KA KAF |
97 D90S4 97 D90S4 97 D90S4 97 D90S4 |
|
5.3 5.6 6.2 7.2 |
1990 1880 1680 1450 |
174.19 164.34 147.32 126.91 |
28100 28200 28300 28500 |
1.35 1.45 1.60 1.85 |
K KF KA KAF |
87 D90L6 87 D90L6 87 D90L6 87 D90L6 |
|
Output speed n2 [r/min] |
Output torque Ta [N*m] |
Ratio i |
Permitted overhung load FR2 [N] |
Service factor fB |
Model |
|
|---|---|---|---|---|---|---|
|
1.1kW |
||||||
|
8.0 8.5 9.5 11 12 |
1310 1230 1110 950 870 |
174.19 164.34 147.32 126.91 115.82 |
28600 28700 28700 28800 28800 |
2.1 2.2 2.4 2.8 3.1 |
K KF KA KAF |
87 D90S4 87 D90S4 87 D90S4 87 D90S4 |
|
6.8 7.2 8.1 9.5 |
1540 1470 1300 1110 |
135.28 128.52 113.56 97.05 |
15400 15900 17000 17900 |
1.00 1.05 1.20 1.40 |
K KF KA KAF |
77 D90L6 77 D90L6 77 D90L6 77 D90L6 |
|
10 11 12 |
1020 690 850 |
135.28 128.52 113.56 |
18300 18400 18800 |
1.55 1.60 1.80 |
K KF KA KAF |
77 D90S4 77 D90S4 77 D90S4 77 D90S4 |
|
14 16 18 19 |
730 670 585 555 |
97.05 88.97 78.07 73.99 |
19200 19300 19500 19600 |
2.1 2.3 2.7 2.8 |
K KF KA KAF |
77 D90S4 77 D90S4 77 D90S4 77 D90S4 |
|
13 14 16 18 20 |
810 770 675 575 515 |
108.03 102.62 90.04 76.04 68.95 |
10400 10700 11400 12000 12300 |
1.00 1.05 1.20 1.45 1.60 |
K KF KA KAF |
67 D90S4 67 D90S4 67 D90S4 67 D90S4 |
|
23 24 29 32 36 |
455 430 365 335 290 |
60.66 57.28 48.77 44.32 38.39 |
12600 12700 12900 13000 13000 |
1.80 1.90 2.2 2.5 2.8 |
K KF KA KAF |
67 D90S4 67 D90S4 67 D90S4 67 D90S4 |
|
16 18 20 23 24 29 32 36 39 46 51 |
675 575 520 455 430 365 335 290 270 225 205 |
90.26 76.56 69.12 60.81 57.42 48.89 44.43 38.49 35.70 30.28 27.34 |
2410 7840 8280 8630 8750 9020 9160 9330 9400 9540 9510 |
0.90 1.05 1.15 1.30 1.40 1.65 1.80 2.1 2.2 2.6 2.9 |
K KF KA KAF |
57 D90S4 57 D90S4 57 D90S4 57 D90S4 |
|
58 62 72 80 92 106 117 124 146 161 186 213 |
181 170 145 132 114 99 90 85 72 65 57 49 |
24.05 22.71 19.34 17.57 15.22 13.25 11.92 11.26 9.59 8.71 7.55 6.57 |
9220 9090 8720 8510 8180 7880 7570 7450 7120 6930 6650 6380 |
3.3 3.5 4.0 4.2 4.7 5.1 4.6 4.9 5.6 6.0 6.4 7.0 |
K KF KA KAF |
57 D90S4 57 D90S4 57 D90S4 57 D90S4 |
|
25 29 30 |
425 365 345 |
56.83 48.95 46.03 |
3310 6360 6610 |
0.95 1.10 1.15 |
K KF KA KAF |
47 D90S4 47 D90S4 47 D90S4 47 D90S4 |
|
35 40 45 48 54 64 72 |
295 265 235 220 194 164 147 |
39.61 35.39 31.30 29.32 25.91 21.81 19.58 |
7090 7090 6960 6890 6730 6510 6360 |
1.35 1.50 1.70 1.80 2.1 2.4 2.7 |
K KF KA KAF |
47 D90S4 47 D90S4* 47 D90S4* 47 D90S4* |
|
47 56 60 69 82 91 107 115 133 157 176 206 220 261 |
225 188 175 152 129 115 98 91 79 60 51 48 40 |
29.96 24.99 23.36 20.19 17.15 15.31 13.08 12.14 10.49 8.91 7.96 6.80 6.37 5.36 |
3420 3440 3440 3420 3370 3330 3260 3220 3140 3040 2970 2870 2830 2720 |
0.90 1.05 1.10 1.20 1.40 1.50 1.70 1.75 2.0 2.4 2.6 2.9 3.0 3.5 |
K KF KA KAF |
37 D90S4 37 D90S4 37 D90S4 37 D90S4 |
