Передаточные числа и максимальный крутящий момент К 67-87 [1]
К 67-87, ne = 1400 1/min
|
K67 820Nm |
||||
|---|---|---|---|---|
|
i |
ne [1/min] |
Mamax [Nm] |
FRa[N] |
AD |
|
144.79 |
9.1 |
820 |
10300 |
AD2 |
|
123.54 |
11 |
820 |
10300 |
|
|
108.03 |
13 |
820 |
10300 |
|
|
102.62 |
14 |
820 |
10300 |
|
|
90.04 |
16 |
820 |
10300 |
|
|
76.37 |
18 |
820 |
10300 |
|
|
68.95 |
20 |
820 |
10300 |
|
|
60.66 |
23 |
820 |
10300 |
|
|
57.28 |
24 |
820 |
10300 |
|
|
48.77 |
29 |
820 |
10300 |
|
|
44.32 |
32 |
820 |
10300 |
|
|
38.39 |
36 |
820 |
10500 |
|
|
35.62 |
39 |
820 |
10300 |
|
|
30.22 |
46 |
820 |
10300 |
AD3 |
|
27.28 |
51 |
820 |
10300 |
|
|
24.00 |
58 |
800 |
10500 |
|
|
22.66 |
62 |
780 |
10700 |
|
|
19.30 |
73 |
760 |
10800 |
|
|
17.54 |
80 |
740 |
11000 |
|
|
15.19 |
92 |
700 |
11300 |
|
|
13.22 |
106 |
670 |
11500 |
|
|
12.48 |
112 |
530 |
12300 |
|
|
10.63 |
132 |
500 |
11800 |
|
|
9.66 |
145 |
480 |
11500 |
|
|
8.37 |
167 |
440 |
11100 |
|
|
7.28 |
192 |
420 |
10700 |
|
|
K77 1550Nm |
||||
|---|---|---|---|---|
|
i |
ne [1/min] |
Mamax [Nm] |
FRa[N] |
AD |
|
192.18 |
7.3 |
1450 |
16100 |
AD2 |
|
179.37 |
7.8 |
1450 |
16100 |
|
|
154.02 |
9.1 |
1550 |
15400 |
|
|
135.28 |
10 |
1550 |
15400 |
|
|
128.52 |
11 |
1550 |
15400 |
|
|
113.56 |
12 |
1550 |
15400 |
|
|
97.05 |
14 |
1550 |
15400 |
|
|
88.97 |
16 |
1550 |
15400 |
|
|
78.07 |
18 |
1550 |
15400 |
|
|
73.99 |
19 |
1550 |
15400 |
|
|
64.75 |
22 |
1550 |
15400 |
|
|
58.34 |
24 |
1550 |
15400 |
|
|
51.18 |
27 |
1550 |
15400 |
|
|
45.16 |
31 |
1550 |
15400 |
|
|
40.04 |
35 |
1550 |
15400 |
AD3 |
|
38.39 |
36 |
1550 |
15700 |
|
|
35.20 |
40 |
1550 |
15400 |
|
|
30.89 |
45 |
1550 |
15400 |
|
|
29.27 |
48 |
1550 |
15400 |
AD4 |
|
25.62 |
55 |
1550 |
15400 |
|
|
23.08 |
61 |
1550 |
15400 |
|
|
20.25 |
69 |
1500 |
15700 |
|
|
17.87 |
78 |
1450 |
16100 |
|
|
15.84 |
88 |
1400 |
15500 |
|
|
13.52 |
104 |
1340 |
14800 |
|
|
12.36 |
113 |
1000 |
15100 |
|
|
10.84 |
129 |
990 |
14400 |
|
|
9.56 |
146 |
940 |
13900 |
|
|
8.48 |
165 |
890 |
13500 |
|
|
7.24 |
193 |
820 |
13100 |
|
|
K87 2700Nm |
||||
|---|---|---|---|---|
|
i |
ne [1/min] |
Mamax [Nm] |
FRa[N] |
AD |
|
197.37 |
7.1 |
2700 |
27300 |
AD2 |
|
174.19 |
8.0 |
2700 |
27300 |
|
|
164.34 |
8.5 |
2700 |
27300 |
|
|
147.32 |
9.5 |
2700 |
27300 |
|
|
126.91 |
11 |
2700 |
27300 |
|
|
115.82 |
12 |
2700 |
27300 |
|
|
102.71 |
14 |
2700 |
27300 |
|
|
86.34 |
16 |
2700 |
27300 |
|
|
79.34 |
18 |
2700 |
27300 |
AD3 |
|
70.46 |
20 |
2700 |
27300 |
|
|
63.00 |
22 |
2700 |
26200 |
|
|
56.64 |
25 |
2700 |
25000 |
|
|
49.16 |
28 |
2700 |
23500 |
|
|
44.02 |
32 |
2600 |
22800 |
|
|
36.52 |
38 |
2500 |
21400 |
|
|
31.39 |
45 |
2700 |
19200 |
AD4 |
|
27.88 |
50 |
2600 |
18500 |
|
|
24.92 |
56 |
2500 |
18000 |
|
|
22.41 |
62 |
2300 |
17900 |
|
|
19.45 |
72 |
2300 |
16800 |
|
|
17.42 |
80 |
2200 |
16300 |
|
|
16.00 |
87 |
1800 |
16000 |
|
|
14.45 |
97 |
2100 |
15300 |
|
|
12.56 |
111 |
2000 |
14800 |
|
|
11.17 |
125 |
1500 |
14900 |
|
|
10.00 |
140 |
1500 |
14200 |
AD5 |
|
8.29 |
169 |
1400 |
13500 |
|
|
7.21 |
194 |
1300 |
13200 |
|
