Передаточные числа и максимальный крутящий момент К 37-57 [1]
К 37-57, ne = 1400 1/min
|
K37 200Nm |
||||
|---|---|---|---|---|
|
i |
ne [1/min] |
Mamax [Nm] |
FRa[N] |
AD |
|
106.38 |
13 |
200 |
5640 |
AD1 |
|
97.81 |
14 |
200 |
5640 |
|
|
83.69 |
17 |
200 |
5640 |
|
|
72.54 |
19 |
200 |
5520 |
|
|
67.80 |
21 |
200 |
5360 |
|
|
58.60 |
24 |
200 |
5020 |
|
|
49.79 |
28 |
200 |
4660 |
|
|
44.46 |
31 |
200 |
4420 |
|
|
37.97 |
37 |
200 |
4100 |
|
|
35.57 |
39 |
200 |
3970 |
|
|
29.96 |
47 |
200 |
3650 |
AD2 |
|
28.83 |
49 |
200 |
3580 |
|
|
24.99 |
56 |
200 |
3330 |
|
|
23.36 |
60 |
195 |
3260 |
|
|
20.19 |
69 |
185 |
3110 |
|
|
17.15 |
82 |
180 |
2900 |
|
|
15.31 |
91 |
175 |
2780 |
|
|
13.08 |
107 |
165 |
2650 |
|
|
12.14 |
115 |
160 |
2600 |
|
|
10.49 |
133 |
160 |
2410 |
|
|
8.91 |
157 |
160 |
2200 |
|
|
7.96 |
176 |
155 |
2110 |
|
|
6.80 |
206 |
150 |
1980 |
|
|
6.37 |
220 |
145 |
1950 |
|
|
5.36 |
261 |
140 |
1810 |
|
|
K47 400Nm |
||||
|---|---|---|---|---|
|
i |
ne [1/min] |
Mamax [Nm] |
FRa[N] |
AD |
|
131.87 |
11 |
400 |
5920 |
AD2 |
|
121.48 |
12 |
400 |
5920 |
|
|
104.37 |
13 |
400 |
5920 |
|
|
90.86 |
15 |
400 |
5920 |
|
|
85.12 |
16 |
400 |
5920 |
|
|
75.20 |
19 |
400 |
5920 |
|
|
69.84 |
20 |
400 |
5920 |
|
|
63.30 |
22 |
400 |
5920 |
|
|
56.83 |
25 |
400 |
5920 |
|
|
48.95 |
29 |
400 |
5920 |
|
|
46.03 |
30 |
400 |
5920 |
|
|
39.61 |
35 |
400 |
5920 |
|
|
35.39 |
40 |
400 |
5920 |
|
|
31.30 |
45 |
400 |
5700 |
|
|
29.32 |
48 |
400 |
5520 |
|
|
25.91 |
54 |
400 |
5170 |
|
|
24.06 |
58 |
400 |
4970 |
|
|
21.81 |
64 |
400 |
4710 |
|
|
19.58 |
72 |
400 |
4440 |
|
|
16.86 |
83 |
380 |
4230 |
|
|
15.86 |
88 |
380 |
4080 |
|
|
13.65 |
103 |
360 |
3890 |
|
|
12.19 |
115 |
350 |
3720 |
|
|
11.77 |
119 |
280 |
4060 |
|
|
10.56 |
133 |
280 |
3830 |
|
|
9.10 |
154 |
280 |
3540 |
|
|
8.56 |
164 |
270 |
3500 |
AD3 |
|
7.36 |
190 |
250 |
3390 |
|
|
6.58 |
213 |
240 |
3270 |
|
|
5.81 |
241 |
230 |
3140 |
|
|
K57 600Nm |
||||
|---|---|---|---|---|
|
i |
ne [1/min] |
Mamax [Nm] |
FRa[N] |
AD |
|
145.14 |
9.6 |
600 |
7470 |
AD2 |
|
123.85 |
11 |
600 |
7470 |
|
|
108.29 |
13 |
600 |
7470 |
|
|
102.88 |
14 |
600 |
7470 |
|
|
90.26 |
16 |
600 |
7470 |
|
|
76.56 |
18 |
600 |
7470 |
|
|
69.12 |
20 |
600 |
7470 |
|
|
60.81 |
23 |
600 |
7470 |
|
|
57.42 |
24 |
600 |
7470 |
|
|
48.89 |
29 |
600 |
7470 |
|
|
44.43 |
32 |
600 |
7470 |
|
|
38.49 |
36 |
600 |
7470 |
|
|
35.70 |
39 |
600 |
7470 |
|
|
30.28 |
46 |
600 |
7310 |
|
|
27.34 |
51 |
600 |
6930 |
|
|
24.05 |
58 |
600 |
6480 |
|
|
22.71 |
62 |
600 |
6280 |
|
|
19.34 |
72 |
575 |
5910 |
|
|
17.57 |
80 |
555 |
5740 |
AD3 |
|
15.22 |
92 |
535 |
5430 |
|
|
13.22 |
106 |
510 |
5190 |
|
|
11.92 |
117 |
415 |
5150 |
|
|
11.26 |
124 |
415 |
4990 |
|
|
9.59 |
146 |
405 |
4650 |
|
|
8.71 |
161 |
390 |
4520 |
|
|
7.55 |
185 |
365 |
4360 |
|
|
6.57 |
213 |
345 |
4190 |
|
